INFICON PCG55x ATM to Medium Vacuum Gauge User Manual
Page 42
42
tina56e1-d (2014-01)
High Trip Point
If the pressure in the vacuum system is higher than the setpoint,
the corresponding LED (
corresponding relay is closed.
Time t
Off
On
Off
Setpoint
M
easure
ment value
Measurement signal
(Pressure p)
Threshold value
Hysteresis
(10% of threshold)
Threshold value
