INFICON BPG402-SD ATM to Ultra-High Vacuum Gauge (DeviceNet) - Manual (Page 13)

tira46e1 (2004-11) BPG402-SDv1.cp
13
Data Component Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Common Exception Detail
Size
0 0 0 0 0 0 1 0
Common Exception Detail 0
0
0
0
Data
Memory
Nonvolatile
Memory
Code
Memory
0 0
Common Exception Detail 1
0 0 0 0
PS Input
Voltage
0 0 0
This structure, similar in form to Common Exception Detail, relates exception con-
ditions which are specific to individual devices on the network and are defined in
the following. The Detail element of the structure is an ordered list (i.e. array) of
bytes of length [SIZE = 4 for Alarms and SIZE = 5 for Warning] which is the value
of the structure element size.
This structure, similar in form to Common Exception Detail, relates exception con-
ditions which are specific to the manufacturers of individual devices on the network.
There is one byte manufacturer exception details defined. The Detail element of the
structure is an ordered list (i.e., array) of bytes of length [SIZE = 1] which is the
value of the structure element Size.
Common Exception Detail
Format Summary
Device Exception Detail
Manufacturer Exception
Detail
