6.3.33 TID
Transmitter identification. Sensor identification. See
Chapter 4.4.3.7 Identifying a sensor, 18.
S: TID
R:
S:
R: a,b,c
6.3.34 TIO
Test I/O. Test the relays. This command allows to switch
a single relay or several relays at a time.
S: TIO[,a,bb]
R:
S:
R: a,bb
NOTE:
The relay status is a hexadecimal number. It may be
combined by the logical operator OR. Example: 24 =
Switching functions relays 3 and 6 on.
6.3.35 TKB
Test keyboard. Test the keyboard.
S: TKB
R:
S:
R: aaaa
The control character
uum Gauge Controller polls the keyboard and sends a
message to the computer.
NOTE:
The keyboard status is a binary number. It may be
combined by the logical operator OR. Example: 0011
= DOWN and UP pressed at the same time.
Parameter
Significance
a
Identification of sensor 1
PSG
PCG
PEG
MPG
CDG
BPG
BPG402
BCG
HPG
noSen
noid
b
Identification of sensor 2
(see above)
c
Identification of sensor 3
(see above)
CAUTION
Relay test.
In this test the relays switch irrespective of the
actual pressure. This may cause unintended
switching of devices.
Unplug the RELAY connection before per-
forming a relay test.
Parameter
Significance
a
Test status
0 = Off
1 = On
bb
Relay status
00 = All relays off
01 = Switching function 1 relay on
02 = Switching function 2 relay on
04 = Switching function 3 relay on
08 = Switching function 4 relay on
10 = Switching function 5 relay on
20 = Switching function 6 relay on
40 = Error signal relay on
7F = All relays on
Parameter
Significance
aaaa
Keyboard status
0000 = No button pressed
1000 = CH pressed
0100 = PARA pressed
0010 = DOWN pressed
0001 = UP pressed
