MPI-16 & MPI-16H POCKET INDEXERS
Appendix A 6-1
6 Appendix A
Quick Reference for Configuration Errors and Faults
The following guide will give you a quick idea of what problem is causing the blinking
when you encounter a Configuration Error or Fault.
Config. Error LED Fault LED
No. Of
Blinks
Error
Description
No. Of
Blinks
Fault
Description
1 Switch Out of Range 1 Abort
2 Circular Pocket 2 Pocket Select
3 No Banana Pockets 3 Over Temperature
4 One Banana Pocket 4 Jam
5 No Second Banana Pocket 5 Position
6 Two Banana Pockets 6 Encoder
7 No Home
8 Firmware
9 Brown-Out
Table 6-1 Quick Reference - Errors and Faults
* Indicates a Fault that may be corrected without a system reset.
For a complete list of Configuration Errors, see Table 3-1.
For a complete list of Faults, see Table 4-5.
