Page 24: Igure, Onfiguration, Xample, Osition, Rucibles
MPI-16 & MPI-16H POCKET INDEXERS
3-6 Setup and Installation
Figure 3-4 Configuration Example - 8-Position Crucibles
3.4.1 Configuration
Error
When the MPI-16 is reset, it scans the five Configuration Switches and internally creates
Pocket Position Tables for use during operation. There are a multitude of Configuration
Switch settings that do not correspond with crucibles that are supported by the MPI-16,
and you will receive a Configuration Error if you try to specify one of these modes. To
help you determine why your switch selection is invalid, the Config. Error LED will
blink a code telling you what type of Configuration Error occurred.
Table 3-1 describes the possible conflicts that cause the Config. Error LED to blink.
8, 0, 0, 0
8, 6, 0, 0
8, 3, 5, 4
