MPI-16 & MPI-16H POCKET INDEXERS
1-4 General Description
1.3 Specifications – MPI-16 Pocket Indexer
1.3.1 Indexing
Number of Positions Supported Circular, 4, 5, 6, 8, 10, 12, 16
“Banana” Pockets Supported Up to 2
Rotation Modes Fast, UHV, CW, CCW, Remote
Position Accuracy and
Repeatability 1
° at output shaft
1.3.2 Speed at Output Shaft
Pocket Search Speed (MPI-16) 16 RPM
Pocket Search Speed (MPI-16H) 16, 8, 4, 2, 1, 1/2, 1/4, 1/8 RPM
Circular, Banana Sweep Speed 16, 8, 4, 2, 1, 1/2, 1/4, 1/8 RPM
1.3.3 Torque at Output Shaft
Max. Torque (MPI-16) 187 in-oz.
Max. Torque (MPI-16H) 310 in-oz.
1.3.4 Temperature
Protection
Auto Shut-off Temperature 100 ± 1
°C (212 ± 1.8°F)
Resume From Shut-off 85 ± 6
°C (185 ± 10.8°F)
1.3.5 Safety
Interlocks
Relay output, SPST 120 VA, 2A max.
Disable Ground true.
4.7 K ohms pull up to 5 VDC internally.
1.3.6 Inputs/Outputs
Interface
Inputs Ground true.
4.7 k ohms pull up to 5 VDC internally.
Input Functions Pocket Selection: 4-bit BCD
Speed Selection: 3-bit BCD
Clockwise rotation selection
Counter Clockwise rotation selection
Reset
Outputs Optically isolated transistors. Ground true.
4.7 K ohms pull-up resistors. 50 mA max.
Output Functions Pocket Position: 4-bit BCD
In Pocket Position
Pocket Fault
