CI-100 Crucible Indexer Operating Manual
2.4 Electrical Connections
WARNING
Be sure the power switch on the CI-100 controller front
panel is OFF.
Plug the power cord into the CI-100 power entry module, then into a 100-120 or
200-240 V (ac), 50/60 Hz mains outlet.
Attach the DB-25 control cable from motor drive to the connector marked Motor on
the CI-100 controller.
The I/O and RS-232/LAN connections are covered later in this chapter. They are
not needed for initial setup.
2.5 Calibration
NOTE: The display flashes E at power-up until this calibration step is completed.
WARNING
Be sure the power switch on the CI-100 controller front
panel is OFF.
CAUTION
Verify that the front panel Manual/Auto switch is set to
Manual, and the Pocket/Jog switch is set to Jog.
1 On the rear panel of the CI-100 controller set the Pocket Type and Select dip
switches to match your indexer. See the Rear Panel section of the next chapter
for a detailed description of the rear panel switches.
2 Push the CI-100 front panel Power switch to the ON position.
3 Press the CW/CCW switch to jog your indexer to Pocket 1. Press and hold the
CW/CCW switch for faster movement.
4 Using the CW/CCW switch, jog the indexer to the exact position you want to
calibrate as “home” for pocket 1.
5 Press and hold the Calibrate switch until the displays stop blinking (about three
seconds). This calibrates pocket one home.
