SendGetRelays
Parameters: None
Return : 16 Bit Integer, always returns a 1.
SendGetRelays is used to retrieve the mapping of the 8 physical relays to the 21
Relay events. This function must precede the use of GetRelays.
GetRelays
Parameters: Pointer to an IO structure (integer array(7).
Return : 16 Bit Integer, always returns a 1.
GetRelays is used to retrieve the mapping of the 8 physical relays to the 21 relay
events. Values in the array(0-7) are the events (0-20) assigned to each input.
Relay events are:
0 = Source Shutter 1 7 = Deposit Phase 14 = Time Setpoint
1 = Source Shutter 2 8 = PreCond Phase 15 = Thickness Setpoint
2 = Sensor Shutter 1 9 = SoakHold Phase 16 = Final Thickness
3 = Sensor Shutter 2 10 = Process Active 17 = Pocket BCD Bit 0
4 = All Sensor Fail 11 = Manual Mode 18 = Pocket BCD Bit 1
5 = Sensor 1 Fail 12 = Max. Power 19 = Pocket BCD Bit 2
6 = Sensor 2 Fail 13 = Stopped 20 = Secondary Sensor
Example:
ReturnVal = SendGetRelays request transfer Relays
do while(ChkCommDone == -1) wait for comm to finish
ReturnVal = GetRelays(&IoP) I/O Sruct contains info
SetRelays
Parameters: Pointer to a I/O Structure.
Return : 16 Bit Integer, always returns a 1.
SetRelays is used to set the event definitions of the eight realys as described
above. All of the parameters are passed to the function through the I/O Structure.
Example:
ReturnVal = SetRelays(&IoP) set Relay events
do while(ChkCommDone == -1) wait for comm to finish
