GetLayer
Parameters: Pointer to a Layer Structure.
Return : 16 Bit Integer, always returns a 1.
GetLayer is used to retrieve a Layer’s parameters (requested by SendGetLayer).
The parameters are passed through the Film Structure.
Example:
ReturnVal = SendGetFilm(FilmNum) tell unit to transfer Film #
do while(ChkCommDone == -1) wait for comm to finish
ReturnVal = GetLayer(&LyrStruct) LyrStruct contains Film info
DeleteLayers
Parameters: None
Return : 16 Bit Integer, always returns a 1.
Delete Layers removes all layers from the active process.
Example:
ReturnVal = DeleteLayers set film parameters
do while(ChkCommDone == -1) wait for comm to finish
Set122Film
Parameters: Film # (16 Bit Integer), Pointer to a Film Structure.
Return : 16 Bit Integer, always returns a 1.
Set122Film is used to set a Film’s parameters in the unit. All of the parameters
are passed to the function through the Film Structure.
Example:
ReturnVal = SetFilm(&FilmStruct) set film parameters
do while(ChkCommDone == -1) wait for comm to finish
SendGetFilm
Parameters: 16 Bit Integer.
Return : 16 Bit Integer, always returns a 1.
