8
RS232
ASCII Interface
Protocol
jins85e1 2.fm Interface Description (1101)
*CONFig read or write parameter –
:AccVol accumulation volume in chosen unit
( 0.01.. 10000 liters and equivalent)
S
R *CONF:AV 1.2
*CONF:AV? OK
1.2
:CALAccess permit calibration ( on / off ) S
R *CONF:CALA ON
*CONF:CALA? OK
ON
:CALFac calibration factor ( 0.1 .. 10 ) S
R *CONF:CALF 1.1
*CONF:CALF? OK
1.1
:CarFlow carrier gas flow in chosen unit
( *CONF:UNIT:FU? )
S
R *CONF:CF 1000
*CONF:CF? OK
1000
:CONTRAST 0 .. 99 R/S *CONF:CONTRAST 15 OK
:CONTROL
control location
(local = keyboard; RS232 = Interface)
–
RS232, LOCAL/RS232; ALL R/S *CONF:CONTROL RS232 OK
CopyParaSET M,N M is the source and N the destination
They can be d,0..3,11..35
d means default (not as destination)
0 is the actual parameter set
1..3 are internally stored
11..35 are stored on the optional I·Stick
S
S *CONF:CPSET 1,0
*CONF:CPSET 33,1 OK
OK
