10
RS232
ASCII Interface
Protocol
jins85e1 2.fm Interface Description (1101)
Command
word1
Command
word2
Command
word3
Parameter Statement Read/
Set
Example Response
*CONFig :PLCOUTLINK PLC output link for one pin –
: pin number = 8 .. 15 R/S
values for PLC output functions: R/S
OPEN S
R *CONF:PLCOUTLINK:9 OPEN
*CONF:PLCOUTLINK:9? OK
OPEN
CLOSE
TRIGGER_1 INV_TRIGGER_1
TRIGGER_2 INV_TRIGGER_2
READY INV_READY
CYCLE_ACTIVE INV_CYCLE_ACTIVE
STANDBY INV_STANDBY
ERROR INV_ERROR
WARNING INV_WARNING
ERR_WARN INV_ERR_WARN
CAL_ACTIV INV_CAL_ACTIV
MEASURE INV_MEASURE
GROSS INV_GROSS
CONTROL_OUT_FUNC_GR_LEAK
CONTROL_OUT_FUNC_INV_GR_LEAK
R/S
R/S
R/S
R/S
R/S
R/S
R/S
R/S
R/S
R/S
R/S
R/S
R/S
R/S
:PROOFleak read/set proof leak rate S
R
*CONF:PROOF 6E-6
*CONF:PROOF? OK
6.00E-6
value = MBAR*L/S, PA*M3/S, SCCM, TORR*L/
S S
R *CONF:PROOF:MBAR*L/S 1.5E-5
*CONF:PROOF:MBAR*L/S? OK
1.50E-5
