RS232 Binary Interface Protocol
31
jin
s
85
e1
4.f
m
In
ter
fa
c
e De
scrip
tion
(1
10
1)
176 Get Standby Delay Read Standby delay
time 0=10 s
1=30 s
2=1 min
3=2 min
4=5 min
5=10 min
6=30 min
7=60 min
8=off
177 Set Standby Delay Set Standby delay
time Byte 0:
0=10 s
1=30 s
2=1 min
3=2 min
4=5 min
5=10 min
6=30 min
7=60 min
8=off
187 Get IO Ports Out IO Port (output) Byte0, Bit0 Pin 8
Byte0, Bit1 Pin 9
Byte0, Bit2 Pin 10
Byte0, Bit3 Pin 11
Byte0, Bit4 Pin 12
Byte0, Bit5 Pin 13
Byte0, Bit6 Pin 14
Byte0, Bit7 Pin 15
188 Get IO Ports In IO Port (input) Byte0, Bit0=Pin1
Byte0, Bit1=Pin2
Byte0, Bit2=Pin3
Byte0, Bit3=Pin4
Byte0, Bit4=Pin5
Byte0, Bit5=Pin6
189 Start Standby
or Purge Byte0:
1= Start Standby
2= Stop Standby
3= Start Purge
4= Stop Purge
190 Get Times Auto Byte 0:
0=Auto Times
1=Auto Purge 0=off
1=on
191 Set Times Auto Byte 0:
0=Auto Times
1=Auto Purge
Byte 1:
0=off
1=on
194 Get Value Byte 0:
0=He Percentage Value [uchar]
195 Set Value Byte 0:
0=He Percentage
Byte 1:
10..100 [uchar]
No. Name Description Parameter Data
