RS232
ASCII Interface
Proto
c
ol
11
jins85e1 2.fm Interface Description (1101)
Command
word1
Command
word2
Command
word3
Parameter Statement Read/
Set
Example Response
*CONFig :RECorder read/write proof leak –
:LINK1_2 analog output 1: –
para = OFF, P1, MANT, EXP, LR_LIN,
LR_LOG, CUR_LIN, CUR_LOG
S
R *CONF:REC:LINK1_2 EXP
*CONF:REC:LINK1_2? OK
EXP
:LINK3_4 analog output 2: –
para = OFF, P1, MANT, EXP, LR_LIN,
LR_LOG, CUR_LIN, CUR_LOG
S
R *CONF:REC:LINK3_4 MANT
*CONF:REC:LINK3_4? OK
MANT
:SCALE1_2 ascent for logarithmic analog output 1..2: –
para = 0.5V/DEC, 1V/DEC, 2V/DEC,
2.5V/DEC, 3V/DEC, 5V/DEC, 10V/DEC
S
R *CONF:REC:SCALE1_2 1V/DEC
*CONF:REC:SCALE1_2? OK
1V/DEC
:SCALE3_4 ascent for logarithmic analog output 3..4: –
para = 0.5V/DEC, 1V/DEC, 2V/DEC,
2.5V/DEC, 3V/DEC, 5V/DEC, 10V/DEC
S
R *CONF:REC:SCALE3_4 2V/DEC
*CONF:REC:SCALE3_4? OK
2V/DEC
:upperEXP1_2 max. value for analog output 1..2
-1 .. -5 = 10
-1
mbarl/s .. 10
-5
mbarl/s
respectively
10 -7 A .. 10 -11 A
S
R *CONF:REC:EXP1_2 -4
*CONF:REC:EXP1_2? OK
-4
:upperEXP3_4 max. value for analog output 3..4 –
-1 .. -5 = 10
-1
mbarl/s .. 10
-5
mbarl/s
respectively
10 -7
A .. 10
-11
A
S
R *CONF:REC:EXP3_4 -1
*CONF:REC:EXP3_4? OK
-1
:PRESSHigh read/write upper pressure limit in mbar –
S
R *CONF:PRESSH 370
*CONF:PRESSH? OK
370
:PRESSLow read/write lower pressure limit in mbar –
S
R *CONF:PRESSL 180
*CONF:PRESSL? OK
180
:STANDBYDel setting for standby delay: –
00:30
#
30 s; 01:00
#
1 min; 02:00
#
2 min;
05:00
#
5 min; 10:00
#
10 min;
30:00
#
39 min; 60:00
#
1 h; 0 = off
S
S
R *CONF:STANDBYD OFF
*CONF:STANDBYD 01:00
*CONF:STANDBYD? OK
OK
01:00
