RS232
ASCII Interface
Proto
c
ol
13
jins85e1 2.fm Interface Description (1101)
Command
word1
Command
word2
Command
word3
Parameter Statement Read/
Set
Example Response
*CONFig :TLRate read / write test leak rate in current unit S
R *CONF:TLR 3.7E-4
*CONF:TLR? OK
3.70E-4
:MBAR*L/S read / write test leak rate in mbar*l/s S
R *CONF:TLR:MBAR*L/S 3.5E-4
*CONF:TLR:MBAR*L/S? OK
3.50E-4
:PA*M3/S read / write test leak rate in Pa*m
3
/s R/S
:SCCM read / write test leak rate in sccm R/S
:TORR*L/S read / write test leak rate in Torr*l/s R/S
:TRIGger1 read / write trigger 1 in current unit –
:MBAR*L/S read / write trigger 1 in mbar*l/s S
R *CONF:TRIG1:MBAR*L/S 5.5E-5
*CONF:TRIG1:MBAR*L/S? OK
5.50E-5
:PA*M3/S read / write trigger 1 in Pa*m
3
/s R/S
:SCCM read / write trigger 1 in sccm R/S
:TORR*L/S read / write trigger 1 in Torr*l/s R/S
:TRIG2ON enable/disable trigger 2 with „ON“ or „OFF“ S
R *CONF:TRIG2ON ON
*CONF:TRIG2ON? OK
ON
:TRIGger2 read / write trigger 2 in current unit –
:MBAR*L/S read / write trigger 2 in mbar*l/s S
R *CONF:TRIG2:MBAR*L/S 5.5E-5
*CONF:TRIG2:MBAR*L/S? OK
5.50E-5
:PA*M3/S read / write trigger 2 in Pa*m
3
/s R/S
:SCCM read / write trigger 2 in sccm R/S
:TORR*L/S read / write trigger 2 in Torr*l/s R/S
