CHAPTER 4 CONTROL PANEL
4–25
■ About Line Settings
Setting the number of lines/page automatically sets the line spacing or line
feed pitch. If the paper size is changed, the number of lines/page changes
accordingly. The new setting is calculated with the following expression
and the remainder, if any, is ignored. However, the line feed pitch and the
top and bottom margins remain effective.
# of Lines/Page =
Page Length – (Top Margin + Bottom Margin)
Line Feed Pitch [Vertical Motion Index (VMI)]
The setting of lines/page is subject to the current paper size and
orientation. For example, when letter-sized paper is used, the printer can
print 60 lines per page in portrait orientation. If the orientation is changed,
the line settings are restored to the factory settings in that orientation.
The following tables show the factory settings in each emulation mode.
In HP Mode In Non-HP Modes
Orientation Orientation
Size Portrait Landscape Size Portrait Landscape
Letter
60 lines 45 lines
Letter
62 lines 47 lines
A4
64 lines 43 lines
A4
66 lines 45 lines
Legal 78 lines 45 lines Legal 80 lines 47 lines
✒ Note
When you use application software in the non-HP modes, the
recommended settings are as follows:
• Left margin = column 0
•
Right margin = Max. value
•
Auto MASK ON
GRAPHICS MODE
✒ Note
The settings in this mode menu are effective only in the HP-GL mode.
They do not appear in any other emulation modes.
Since the HP-GL emulation mode is for a plotter, you can select the
plotter pens, the pen size and percentage of gray in this mode menu.
