CHAPTER 4 CONTROL PANEL
4–9
Mode Menu (Continued) Setting Menu Sub-Setting Menu Setting
INTERFACE MODE
(Continued)
I/F AUTO
(Continued)
MIO Setting Available only when a
commercial MIO card has been
installed. The settings available
on the installed MIO card can
appear under the sub-setting
menu.
FORMAT MODE ORIENTATION ORI=PORTRAIT PORTRAIT or LANDSCAPE
AUTO MODE AUTO LF=OFF ON … LF + CR
OFF … CR only
AUTO CR=OFF ON … LF, FF, or VT + CR
OFF … LF, FF, or VT only
AUTO WRAP=OFF ON … Auto wrap on
OFF … Auto wrap off
AUTO SKIP=ON ON … Auto FF at bottom
margin
(HP mode) OFF … No FF at bottom
margin
AUTO MASK=OFF ON … Auto mask on
(EPSON & IBM modes) OFF … Auto mask off
exit Exit to AUTO MODE
PAGE FORMAT MODE PAPER =LETTER
(For 110/120V model)
PAPER =A4
(For 220/240V model)
LETTER, LEGAL, A4, A5,
A6, B5, B6, EXECUTIVE,
COM10, MONARCH, C5 and
DL
LEFT M = 0C 0 to 126 columns
RIGHT M = 80C
(Letter, Portrait)
10 to 136 columns
RIGHT M = 78C
(A4, Portrait)
10 to 136 columns
TOP M =0.5” (HP mode) 0, 0.33, 0.5, 1.0, 1.5, or 2.0”
BOTTOM M=0.5”
(HP mode)
0, 0.33, 0.5, 1.0, 1.5, or 2.0”
LINES = 60L
(HP, Letter, Portrait)
5 to 128 lines/page
LINES = 64L
(HP, A4, Portrait)
5 to 128 lines/page
X OFFSET= 0 -500 (left) to +500 (right) dots
Y OFFSET= 0 -500 (down) to +500 (up)
dots
exit Exit to PAGE FORMAT MODE
exit Exit to FORMAT MODE
RESOLUTION MODE RESOLUTION RESOLUTION 300 or 600 dpi
HRC SETTING HRC=MEDIUM OFF, LIGHT, MEDIUM, or
DARK
exit Exit to RESOLUTION MODE
PAGE PROTECTION
PROTECT=AUTO AUTO, OFF, LETTER, A4, or
LEGAL
CARD OPERATION When the commercial flash memory card or the HDD card has not been formatted:
(HP mode only)
FORMAT CARD Format the flash memory card or
the HDD card.
exit Exit to CARD OPERATION
