CHAPTER 2 GETTING STARTED
2–15
1. Open the multi-purpose tray by pressing the front door of the tray
lightly and lowering it gently.
✒ Note
Pull out the extension tray of the multi-purpose tray for long paper if it is
necessary.
Fig. 2-19 Opening the Multi-purpose Tray
and Pulling Out the Extension Tray
2. Lift up and slide the paper width guide to the far right side.
3. Place a stack of paper or envelopes on the tray until it is securely
seated.
✒ Notes
When you place paper on the multi-purpose tray, note the following:
• The print surface must be face up.
• The leading edge must be placed inside first and lightly against the
printer.
•
The left side must be aligned with the left guide.
• The top of the paper stack must be under the holders on both sides of
the tray. The maximum thickness is 16.5 mm or 0.65 inches.
