Manual (auto tracking off): you can manually move the laser head using the
userinterface or the management (will refer to that on next page). Userinterface:
green LED.
Signal power(1-9=ok): Important that these signal power has no any connection to
the receiving level. 0 - too little light. 10: too much light. 1-9: Tracking is working, but
the optimum range is:3-8.
Signal position: [0-100], [0-100] tracking signal position. X and Y position (in %), so
the system seeks 50 and 50 %.
Detector level: shows the local heads received level. In volts, the maximum is 7
volts and the minimum is 0.2 volts. The value will display error depeding on the
setting was done device setup.
Remote is visible: this status information is a good information about the connection
over the two laserheads if this status is OK that means that there is data transferred
over the link.
AGC: Automatic GAIN Control. Tries to keep level of GAIN. Useful to use at big
distances and when visibility often and many times changes (fog, etc.).AGC:0 or 1
Gain: Actual strengthening of tracking signal (Currently maximum 9) which should be
increase at small detector level.
Beam searching method: Beam-Search Algorithm: Try to find the laser beam if a
big and sudden movement have occurred which falls out of tracking field of view.
Useful to use on such installation sites where many movement of laser head can
happen. Possible levels: Disabled, Short, Long.
Beam searching activity: Beam searching actual status. Possible values: idle,
LastGood(a/b),
LG-X(a/b),
LG-CIRCLE(a/b),
LG-CIRCLE2(a/b),
Center,
C-
CIRCLE(a/b) where „a” is the actual status of level part, „b” number of level parts.
Last good motor position: Saving against turning Off (blackout) happens daily.
Motor position: positions of tracking motors.
Auto Focus adjustment
(auto tracking off): this mode can’t be turned ON on the
web only on the useriterface. If you have turned on the Auto Focus then you will be
able to adjust the laser beam size. Userinteface: LED is dark (no color).
