Inserting the computer into Cradle
Make sure that the cradle Latch is in the 1.
open positon before inserting computer.
With the computer held at an angle
insert the front edge of the handle under
the front tabs. (see Figure 2).
Finish by setting the back of the 2.
computer onto the cradle so that it is flat.
Press the latch until it is fully engaged
and remains closed. (see Figure 3)
To remove computer make sure 3.
computer is turned off and reverse
procedure above.
Figure 2
Figure 3
Latch
Page 2 of 2
4. The Screen Support provided with the
cradle can be attached to the right or
left side. Use the supplied #8-32 x .38
long screws to attached the screen
support to the cradle.
(See Figure 4)
#8-32 x .38 Screws
Figure 4
