Components
Bottom View
DC IN 16V
DSUB 9-PIN Male
Will not support serial mouse.
Front View
2 of 6
IEEE 802.3 10Base-T / IEEE 802.3u
100Base-TX
(4 PIN, USB2.0)
FIG. A
FIG. B
LAN Port
USB Ports (3 ports)
DC-IN Jack
Serial Port
External Display Port
MINI DSUB 15-PIN Female
Actuator Button
Latching
Mechanism
Lock (Optional)
Expansion Bus
