Gamber-Johnson 7160-0343 User Manual
Page 2
Installation on MAG Docks:
The bracket can be installed in conjunction with a Screen Support and/or
LED Light Assembly.
1. Install bracket to MAG Dock using supplied screws and washers. Caution:
Do not over tighten screws as damage may result to MAG Dock threads.
2. Install Pro.Fit accessory to Lock Plate
3. Loosen Lock Nut and snap Lock Plate/Lock Nut assembly onto ball.
4. Adjust position as required and tighten Lock Nut
Installation on NotePad V:
The bracket can be installed in conjunctionwith a Screen Support or LED
Light Assembly.
1. Install Bracket to NotePad V using supplied screws and washers.
2. Install Pro.Fit accessory to Lock Plate
3. Loosen Lock Nut and snap Lock Plate/Lock Nut assembly onto ball.
4. Adjust position as required and tighten Lock Nut
7160-0096
MAG DOCK
7160-0060
7160-0251
OR
7160-0252
NOTEPAD V
