53
Motion / Continuous
Motion / PreAlarm
Motion / Alarm In
Motion / Alarm In / Continuous
Motion / Alarm In / PreAlarm
 Choose ‘OK’ to confirm the setting.
(NOTE)
Holiday (H) registration is done with a separate menu.
4.5.3 Pre Alarm
A, B, C, D, E and F Type
 Please ( ) RECORD>Pre Alarm and the following will appear.
 Pre Alarm is effectively used when user selected recording mode by Alarm or Motion.
 The Pre Alarm will allow user to check, during playback, the previously recorded video before the record start time.
 Each frame on Title column shows camera title registered in DEVICES>Camera/PTZ. User cannot change camera titles
here.
 Click ( ) each frame on Resolution column to select recording resolution of a corresponding camera. User may select one
of 720x480, 720x240 and 360x240. (NTSC)
 Click ( ) each frame on Frames column to select recording rate of a corresponding camera. Recording rate varies by
camera. Below lists the maximum recording rate of each camera.
A, B and C Type
NTSC(PAL) 360x240 (360x288) 720x240 (720x288) 720x480 (720x576)
4 Channel DVR 120 (100) 120 (100) 60 (50)
8 Channel DVR 240 (200) 120 (100) 60 (50)
16 Channel DVR 480 (400) 240 (200) 120 (100)
D and E Type
NTSC(PAL) 360x240 (360x288) 720x240 (720x288) 720x480 (720x576)
4 Channel DVR 120 (100) 120 (100) 120 (100)
8 Channel DVR 240 (200) 240 (200) 120 (100)
