47
4.5 RECORD
 Please click ( ) RECORD and the following screen will appear.
4.5.1 Setting
A, B, C, D, E and F Type
 Please click ( ) RECORD>Settings and the following screen will appear.
 There are three kinds of recording mode.
- Continuous: record continuously.
- Event: record only when Sensor or Motion calls.
- Emergency: record when press EMERGENCY key.
 The Continuous menu will allow user to set recording mode.
 Each frame on Title column shows camera title registered in DEVICES>Camera/PTZ. User cannot change camera titles
here.
 Click ( ) each frame on Resolution column to select recording resolution of a corresponding camera. User may select one
of 720x480, 720x240 and 360x240. (NTSC)
 Click ( ) each frame on Frames column to select recording rate of a corresponding camera. Recording rate varies by
camera. Below lists the maximum recording rate of each camera.
A, B and C Type
NTSC(PAL) 360x240 (360x288) 720x240 (720x288) 720x480 (720x576)
4 Channel DVR 120 (100) 120 (100) 60 (50)
8 Channel DVR 240 (200) 120 (100) 60 (50)
16 Channel DVR 480 (400) 240 (200) 120 (100)
D and E Type
Continuous
