System Manual Safety System CES-A-S5H01

7

Block diagram

M

~

~

M

1

1

0 V

24 V

D0

D1

D2

D3

+LA

+LB

Coded

actuator

Trans-

ponder

Read head with

evaluation unit

CES-A-S5H-01

Connection:

M23 plug connector

12-pin, screened

PLC

control system

Read head

Contactor X

Contactor Y

Output circuit for output A:

Pin assignment:

Pin

1

2

3

4

5

6

7

8

9

10

11

12

Function

LA

+LA

+UB

+LB

LB

0V

NC

D0

D1

D2

D3

NC

View on connector

for the safety switch

LA

+LA

LB

+LB

D0

D1

D2

D3

Safety outputs LA, LB with operating voltage +LA, +LB suitable for sensor pulsing (PSS)

Monitoring outputs for dog no. Operating voltage +UB, not suitable for sensor pulsing

Safety

CPU A

Safety

CPU B

Dog

CPU

Safety

DDSP

Read coil

Double

dynamic

safety

path

0V

Screen bonding clamp

LA

LB

1

2

3

4

5

6

7

8

9

10

1

12

Screen

bonding clamp

1

2

5

4

8

9

10

1

+UB

3

6

Plug housing

or

cable screen

State

YE Out
RD ERROR

EUCHNER

Safety switch

CES-A-S5H-01

ID.-NR.:090640

SER.-NR.: . . .

D3 D2 D1 D0
