System Manual Safety System CES-A-S5H01
5
Actuator CES-A-BBA
Cube-shaped design 4 x 5 mm
CES-A-BCA suitable for use in aggressive media (e.g. acids, alkalis)
Dimension drawing CES-A-BBA
Technical Data
Parameter
Value
Unit
min. typ. max.
Housing material
- CES-A-BBA Fortron, reinforced thermoplastic, fully encapsulated
Flat seal material (CES-A-BCA only) Fluororubber 75 FPM 4100
Dimensions 4 x 5 x 1 mm
Weight 0,0 kg
Ambient temperature
°C
- CES-A-BBA -5 - +70
Degree of protection IP67/IP69K
Installation position Active face opposite read head
Power supply Inductive via read head
Ordering table
Series Comment Version Order no. / item
CES-A-BBA safety screws M4 x 14 are supplied -
071840
CES-A-BBA


Approvals Approvals
CES-A-B 071840
25
ш8 ш4
,5
42
32 ±0,1
12
4,6 Active face Active face
safety screws M4 x 14
are supplied
