System Manual Safety System CES-A-S5H01
1
Technical Data
Note
If a product data sheet is included with the product, the information on the data
sheet applies in case of discrepancies with the operating instructions.
Safety switch CES-A-S5H-01
Read head and evaluation unit integrated in the standard housing
Semiconductor output
M1 plug connector
Dimension drawing
Switching characteristics
safety outputs
(semiconductor outputs)
4 data outputs for actuator
number (semiconductor
outputs, not safety output)
Note
The data outputs D0, D1, D, D3 have no safety function.
The safety outputs LA and LB as well as the data outputs D0, D1, D, D3 are
short circuit-proof.
Typical operating distance
See page 4 and page 7
Approvals
Approvals
±0,1
Ø
60
M x1
7,3
30
5,3
±0,1
7,3
23
23
46,5
11
9
D3 D2 D1 D0
16,5
12,5
40
40,5
LED
State
indica-
tion
LED indicator:
dog number
Active face
Safety guard
closed
(actuator detected)
open
(actuator not in the operating
distance)
Read head Safety
actuator
Read head
+LA
LA
+LB
LB
24 V
D0
+LA
LA
+LB
LB
24 V
D0
24 V
D1
24 V
D2
24 V
D3
24 V
D1
24 V
D2
24 V
D3
