Unpack and Organise
3
S e c t i o n 1
Unpack and Organise
The table below lists the parts and components needed to retrofit a CE Sensor rack
(ESR12, 24, 36 or 48) to become a Sensor3 rack with a CEM3. Each part is listed to reflect
the different quantities for the different kits and types of racks.
* Need/quantity based on specific rack type. For details contact ETC Technical Services (see
Parts/Components
ETC Part Number
ESR12 Rack
7144K1000
ER24-48 Rack
7144K1001
Part
s In
clud
ed in the Kit
s
Beacon Door Acrylic
7051A4116
1
1
CAT5 Termination Kit
4101A2003
1
1
Sensor3 Beacon Blue Assembly
7141B5109
1
1
Sensor3 Install Rack Door Label
7141A4001
1
1
8-pin Screw Terminal Data Connector
J3407-F
2
2
ECEM Classic to CEM3 Power Adapter Harness, ESR12
7144B7002
1
ECEM Classic to CEM3 Power Adapter Harness, ESR24-48
7144B7003
1
CE Sensor3 Install Rack Backplane Assembly, Sgl Height
7144A2000-CFG
1
CE Sensor3 Install Rack Backplane Assembly, Dbl Height
7144A2001-CFG
1
Sensor+/3 Filler Module
7150A3010
1
Sensor Rack CEM Classic to CEM3 Retrofit Manual
7144M2310
1
1
CAT5e Cable RJ45/RJ45 UTP 2ft
N4035
1
1
Screw 6-32 X 3/8 Ph PH MS CP W/Patch
HW222
3
3
Screw M4 X 10mm Ph PH MS W/Patch
HWM1346
3
3
Cable tie 4" Hi-temp Black
HW7121
28
28
CEM3 Backplane 1/8” #8 screw spacer
HW9343
3
3
Tie-mount (sticky-back)
HW741
14
14
Heat Shrink 1-1/2” x 4-1/2” Black
W682
2
2
Additional Items
Additio
nal
Li
ne Items
Sensor3 AF Card (for all AF racks)
7150B5623
up to 4*
CEM3
7140A1001
1
