Overview 11
Control Values for the Standard 12-Color Gel String
Reset Channel
To use the Reset Channel (Channel 12), set the channel to one of the levels shown below
for three seconds, then set the channel to 0% without timing or fading. The fixture will
recalibrate the functions associated with the reset level and return to the settings provided
by the incoming DMX data.
Frame Gel Number a
a) R = Roscolux and Rosco Supergel numbers, L = Lee.
Gel Name
Percent
Start
Percent
End
Percent
Center
Frame
DMX
Start DMX
End
DMX
Center
Frame
0 (Leader) — Open White 0% 7% 3% 0 17 9
1 R02 Bastard Amber 7% 14% 11% 18 36 27
2 R05 Rose Tint 15% 21% 18% 37 54 46
3 R09 Pale Amber Gold 22% 28% 25% 55 72 64
4 R54 Special Lavender 29% 35% 32% 73 90 82
5 R357 Royal Lavender 36% 43% 39% 91 109 100
6 R36 Medium Pink 43% 50% 46% 110 127 119
7 R25 Orange Red 50% 57% 54% 128 145 137
8 L203 1/4 C.T. Blue 57% 64% 61% 146 164 155
9 L201 Full C.T. Blue 65% 71% 68% 165 182 174
10 R68 Sky Blue 72% 78% 75% 183 200 192
11 R88 Light Green 79% 85% 82% 201 218 210
12 L-HT115 Peacock Blue 86% 93% 89% 219 237 228
13 (Trailer) — Open White 93% 100% 97% 238 255 247
Reset Function DMX Percent DMX Decimal
Reset entire fixture 75 185-190
Reset scroller and lenses only 60 147-152
Reset Pan and Tilt only 50 126-129
Reset Front Module only 40 97-102
Reset Rear Module only 30 72-77
