Solo Hornet Installation Guide Installation
MAN-SOLHRNIG (Ver. 1.003)
www.elmomc.com
46
4.9. Communications
The communication interface may differ according to the user’s hardware. The Solo Hornet can
communicate using the following options:
a. RS-232, full duplex
b. RS-422, Differential RS-232
c. CAN
RS-232 communication requires a standard, commercial 3-core null-modem cable connected
from the Solo Hornet to a serial interface on the PC. The interface is selected and set up in the
Composer software.
Differential RS-232 (RS-422)communication requires four wires connected from the Solo
Hornet to a controller . The RS-232 interface is selected and set up in the Composer software.
In order to benefit from CAN communication, the user must have an understanding of the basic
programming and timing issues of a CAN network.
For ease of setup and diagnostics of CAN communication, RS-232 and CAN can be used
simultaneously.
