4.7. Auxiliary Feedback – J2
Pin (J2) Signal Function
1 VL+ Auxiliary Power Supply
2 PR Auxiliary Power Supply RET
3 PE Protective Earth
4 CHAO-
Buffered Channel A complement output
5 CHAO
Buffered Channel A output
6 IN 6
Hi-Speed Programmable input 6 (event capture, Main Home,
general purpose, RLS, FLS, INH)
7 IN_RET
Programmable input return
8 INDEXO
Buffered Index output
9 INDEXO-
Buffered Index complement output
10 OUT 1
Programmable digital output 1
11 OUT_RET1
Programmable digital output return 1
12 OUT 2
Programmable digital output 2
13 OUT _ RET2
Programmable digital output return 2
14 IN 1
Programmable input 1 (general purpose, RLS, FLS, INH)
15 IN 2
Programmable input 2 (general purpose, RLS, FLS, INH)
16 IN 3
Programmable input 3 (general purpose, RLS, FLS, INH)
17 IN 4
Programmable input 4 (general purpose, RLS, FLS, INH)
18 IN 5
Hi-Speed Programmable input 5 (event capture, Main Home,
general purpose, RLS, FLS, INH)
19 CHBO
Buffered Channel B output
20 CHBO-
Buffered Channel B complement output
21 ANLRET Analog Return
22 ANLIN1+
Analog input 1+
