Chapter 3: Technical Information
3.1. Technical Data
Feature Units
15
/48
20
/48
5/
60
10
/60
15
/60
20
/60
2.
5/
100
5/
100
15
/10
0
20
/10
0
Minimum supply voltage VDC 6 7.5 12
Nominal supply voltage VDC 42 50 85
Maximum supply voltage VDC 48 59 95
Maximum continuous
power output
W 600 800 240 480 720 960 200 400 1200 1600
Efficiency at rated power
(at nominal conditions)
% > 99
Maximum output voltage > 95% of DC bus voltage at f=22 kHz
Auxiliary power supply VDC 11 – 95 VDC (up to 2.5 VA inc. 5 V/200 mA for encoder)
Amplitude sinusoidal/DC
continuous current
A 15 20 5 10 15 20 2.5 5 15 20
Sinusoidal continuous
RMS current limit (I
c
)
A 10.6 14.1 3.5 7 10.6 14.1 1.8 3.5 10.6 14.1
Peak current limit A 2 x I
c
Weight g (oz) 68.4 g (2.4 oz)
Dimensions mm (in) 59 x 24.7 x 50 (2.32" x 0.97" x 1.86")
Digital in/Digital
out/Analog in
6/2/1
3.1.1. Auxiliary Supply
Feature Details
Auxiliary power supply Isolated DC source only
Auxiliary supply input voltage 11 VDC to 95 VDC
Auxiliary supply input power <2.5 VA (this includes the 5 V/200 mA load for
the main encoder only)
