Cymbal Installation Guide Technical Specifications
MAN-CYMIG (Ver. 1.3)
36
Chapter 5: Technical Specifications
5.1. General Specifications
Feature Units 70/48 70/60 R90/60 50/100 R75/100 35/200 R60/200 18/400
Minimum supply
Voltage VDC 11 12 18 36 72
Nominal supply
Voltage VDC 42 50 85 170 360
Maximum supply
voltage VDC 48 59 95 195 390
Maximum
continuous power
output W 3200 4000 5100 4600 6900 6600 11300 6800
Efficiency at rated
power % > 97
Maximum output
voltage 97% of DC bus voltage at f=32 kHz
DC and trapezoidal
commutation
continuous current
limit (Ic) A 70 70 90 50 75 35 60 18
Peak current limit A 2 x Ic 2 x Ic No
Peak
2 x Ic No Peak 2 x Ic No Peak 2 x Ic
Weight g (oz) 700 g (24.7 oz)
Dimensions mm (in) 134 x 95 x 60 (5.3" x 3.7" x 2.4")
Mounting method Panel mount
Auxiliary power
supply Isolated DC source
only
Auxiliary supply
input voltage 24 VDC ± 30%
Auxiliary supply
input power 2 VA
