Cymbal Installation Guide Installation
MAN-CYMIG (Ver. 1.3)
26
Pin Signal Function Description Pin Location
12 ECLP External
current limit
peak External voltage scales down the
rated value.
Voltage range: 0 V to 3.75 V (3.75 V
= rated Ip)
13 ECLC External
current limit
continuous External voltage scales down the
rated value.
Voltage range: 0 V to 3.75 V (3.75 V
= rated Ic)
14 EN+ Enable + Positive voltage input of the
“Amplifier Enable” function.
To enable operation of the
amplifier, the optocoupler must be
energized by applying voltage
between this pin (+) and pin J2/15
(‐).
The optocoupler is isolated from
the amplifier.
“OFF” voltage: 0 V < Vin < 1 V.
“ON” voltage: 2.5 V < Vin < 10 V,
5 V typically with current
consumption 2.5 mA.
15 EN‐ Enable ‐ Negative voltage input of
“Amplifier Enable” function.
Optocoupler is isolated from the
amplifier.
For details, see pin J2/14.
Table 7: J2, Control Connector Cable‐ Pin Assignments
Note:
All of the XXRETs are shorted internally.
