4.4. Status Indications
The following table lists the Cymbal amplifier status indications.
Function
Latch
Option
AOK
SO1
SO2
SO3
1
Amplifier OK (AOK)
N/A
Low
Open collector
Open collector
Open collector
2
External disable
No
Low
Low
Open collector
Low
3
Current limit
No
Low
Open collector
Open collector
Low
4
Short
Yes
Open
collector
Low
Open collector
Low
5
Over temperature
Yes
Open
collector
Open collector
Low
Low
6
Internal supplies
protection
No
Open
collector
Low
Low
Open collector
7
Under voltage
No
Open
collector
Low
Open collector
Open collector
8
Over voltage
No
Open
collector
Open collector
Low
Open collector
9
Shunt*
No
Low
Open collector
Low
Open collector
10 Power up reset
No
Open
collector
Open collector
Open collector
Open collector
11 Commutation failure
Yes
Open
collector
Low
Low
Low
* This indication can be used as a digital input for activating an external shunt regulator.
Table 10: Cymbal Status Indications
Notes:
• Without latch mode:
The status indications are reset when the fault disappears.
• With latch mode:
The Short, Over Temperature and Commutation Failure status indications are reset when
the enable signal is temporarily removed from the enable input.
• Multiple faults:
Only the reading of the first fault is reliable. Additional faults add on to the status outputs
and the indication is therefore meaningless.
