Monitor callout drawing – Elkhart Brass Sidewinder 7161 EXM UHP User Manual
Page 25
EXM UHP– Monitor Callout Drawing
25
Monitor Callout Drawing –
Figure 1: 7161
EXM UHP Monitor
5000 Series Electronically Actuated Nozzle
1.5” NHT Discharge
Fully-vaned Cast
Aluminum Waterway
Manual Override
Double Race Bearings
2.5” NPT Inlet Base
Sealed High-
Torque Gearmotor
Absolute Position
Feedback
