EXM UHP – Table of Contents
2
Table of Contents –
Product Safety Information……………………………………………………….…………..3
System Components……………………………………………………………..…………....4
Installation Instructions…………………………………………………………………..…...6
Installation Overview………………………………………………..…………....…..6
Installation Step 1 – Mount and Wire All System Components…………...................7
Installation Step 2 – Configure the EXM System…………………………..……….10
Installation Step 3 – Calibrate the EXM System…………………………………….14
Installation Step 4 – Check Installation…………………………..……………..…...15
Operating Instructions……………………………………………………………...…..……16
A. Button / Joystick Operation
B. Setup Mode
C. Re-Calibrating Rotation
D. Travel Limits
E. Keep-Out Zones
F. Stow Position
G. Motor Speed
H. Clear All Function
I. Oscillation
J. Auxiliary
K. Write Diagnostic File
L. Firmware Update
Maintenance Instructions……………….…………………………………..………..……....23
A. Preventive Maintenance B. Understanding System LEDs
System Specifications…………………..…………………………………………....……....24
Monitor Callout Drawing……………………………………………..……………………..25
Component Mounting Templates………………………………………....…………………27
To view the most current parts list, drawings, or demonstrations of common EXM commands,
please visit www.elkhartbrass.com .
