1 95-8527 19.2
Important
Be sure to read and understand the entire
instruction manual before installing or operating
the flame detection system. Any deviation from
the recommendations in this manual may impair
system performance and compromise safety.
attEntIon
The X3301 includes the Automatic oi ® (Optical
Integrity) feature — a calibrated performance test
that is automatically performed once per minute
to verify complete detector operation capabilities.
testing with an external test lamp is not
approved or required.
DESCRIPTION
The X3301 is a multispectrum infrared (IR) flame
detector. It provides unsurpassed detection of fires
from light to heavy hydrocarbon fuels combined with the
highest degree of false alarm rejection. The detector
has Division and Zone explosion-proof ratings and is
suitable for use in indoor and outdoor applications.
The X3301 contains three IR sensors with their
associated signal processing circuitry. The standard
output configuration includes fire, fault and auxiliary
relays. Output options include:
– 0 to 20 mA output (in addition to the three relays)
– Pulse output for compatibility with existing Detector
Electronics Corporation (Det-Tronics ® ) controller
based systems (with fire and fault relays)
– Eagle Quantum Premier ® (EQP) compatible model
(no analog or relay outputs)
– HART communication
A tri-color LED on the detector faceplate indicates
normal condition and notifies personnel of fire alarm or
fault conditions.
Microprocessor controlled heated optics increase
resistance to moisture and ice.
The X3301 housing is available in copper-free aluminum
or stainless steel, with NEMA/Type 4X and IP66/IP67
rating.
OuTpuTs
Relays
The standard detector is furnished with fire, fault and
auxiliary relays. All three relays are rated 5 amperes
at 30 Vdc.
The Fire Alarm relay has redundant terminals and
normally open / normally closed contacts, normally
de-energized operation, and latching or non-latching
operation.
The Fault relay has redundant terminals and normally
open contacts, normally energized operation, and
latching or non-latching operation.
INsTRuCTIONs
Multispectrum IR Flame Detector
X3301
© Detector Electronics Corporation 2013 Rev: 12/13
