Quick start guide Settings
27
ENGLISH
Settings
This section describes how to set the tear position, the first printing line, the print
head gap as well as the font selection and the character density.
` Setting the tear position
If the tear position of the paper is not aligned with the tear edge of the top cover of
the printer, you can adjust it. Inserted paper needs to be torn off if necessary and
retracted to park position.
Press the Setup key. The printer changes to setup mode.
Press the Adjust (2) key.
Press the Tear (4) key.
Swing the soundproofing cover towards the front (see “Printer at a glance”,
page 5). The tear edge is located at the front side of the paper output opening.
Press the < (2) or > (3) key to move the perforation to the desired position. Con-
firm the input by pressing the Set (1) key.
Confirm the input again by pressing the Setup key. The printer is reset to the initial
status.
The correction made – a maximum of approx. 1" (2.5 cm) in each direction – will
be retained after switching the printer off. It can be set separately for each paper
path.
Adjust Paprpath
Menu Char Online
Setup
2 1 3 4
TOF
Head Tear Online
Setup
2 1 3 4
TearAdj= 00/72"*
Set
< > Exit Online
Setup
2 1 3 4
