Model EZGas Pro gas burner — Instruction manual
Carlin part number MNEZGas Rev. 10/28/13
– 20 –
Where appliance instructions differ from this manual, follow the appliance instructions.
9. Replacement parts
Item Number
Description
Part Number
1
Air tube used with universal flange
*Consult Carlin for welded flange airtubes
10” air tube
50877A
12” air tube
50877B
14” air tube
50877C
16” air tube
50877D
18” air tube
50877E
2
Gasket, mounting flange
50821
3
Blower housing
contact factory
4
Air band, 1-slot
50866
4a
Air band, 2-slot
50867
5
Airflow switch
50806
6
24VAC transformer
50822
7
Air flow switch cover
50837
8
Gas valve, VR8305M
50824
9
Gas orifice nipple, 3/4” NPT both ends 4”
Starter hole orifice
9983440XX
Drilled to size
Contact factory
10
Escutchean plate
98548A
11
Blower wheel
77933
12
Motor, Carlin PSC, 1/15 HP
98629
13
Junction box, 4” x 4”, with grommet and lock washer
contact factory
14
Access cover
98281A (without tab)
98282A (with tab)
15
Hinged cover plate for Carlin ignitor
98498
16
Ignitor, Carlin electronic Model 41800
4180002
17
Primary control, Carlin 60200FR microprocessor flame
rod control
6020002FR
18
Ignitor electrode/flame rod assembly
for 10-inch air tube 50875A
for 12-inch air tube 50875B
for 14-inch air tube 50875C
for 16-inch air tube 50875D
for 18-inch air tube 50875E
19
Electrode bracket with screw
50868S
20
Flame rod
for 10-inch air tube 50874A
for 12-inch air tube 50874B
for 14-inch air tube 50874C
for 16-inch air tube 50874D
for 18-inch air tube 50874E
21
Ignitor electrode
for 10-inch air tube 50873A
for 12-inch air tube 50873B
for 14-inch air tube 50873C
for 16-inch air tube 50873D
for 18-inch air tube 50873E
