C.B.S. Scientific DCX-700 - Manual (Page 9)

9 www.cbsscientific.com
4
5. Slide pre-cast gel cassette or plate set(s)
into the core assembly with the notched
plate facing in towards the upper buffer
reservoir as shown in figure 4. If using a
pre-cast gel stored at 4°C, allow to warm
to room temperature. If pouring your
own gels please see Alternate Protocol
(Section 4) on pages 12-14 describing
gel casting using Gel Wrap™.
6. If running one gel, slide white plastic
adaptor plate into the side without the
gel. If running a Lonza 10cm x 9cm gel
casssette place clear shim as shown in
figure 5.
7. Close doors and relatch by pressing
down on the white latches so that the
assembly looks like that shown in figure
6.
8. Place stirring bar into bottom of reservoir
in stirring corral (as shown in figure 7 on
page 10).
9. If using freezer blocks, take frozen
blocks out of freezer and insert into
receptacles on either side of lower res-
ervoir.
5
6
