11 www.cbsscientific.com
matching
colors
8
9
4. Attach safety cover and turn on magnetic
stirrer. The closed unit ready for power is
shown in figure 8.
5. Connect the leads to the power supply,
matching the color-coded red to red and
black to black.
See Section 6.1 for rec-
ommended power conditions. Begin
separation by electrophoresis.
3.3 Removing the Gel
1. Turn the power supply off and discon-
nect the leads from the power supply.
Remove the safety cover from the unit,
by placing thumbs on white posts next
to red & black connectors, then pushing
down while pulling up with fingers under
lid as shown in figure 9.
Do not remove safety cover by pulling
up on leads!
2. Pull up on gel door latches, and open gel
door. Remove gel sandwich from Cas-
sette Assembly. Stain and fix according
to your preferred method.
