8
Dual Cool DCX-700 Instructions 9-30-13
SECTION 3
Instructions for Slab Gel Electrophoresis Using Pre-Cast Gels
3.1 Preparing the Electrophoresis Unit
1. Power leads are shipped separately and
must be attached before using your
Dual Cool. Thread the power lead ends
into the lid receptacles and rotate in
clockwise direction to hand tighten.
2. Place unit in authorized work area. Re-
move safety cover from the assembled
unit by simultaneously pressing down on
white push pins while lifting up on blue
safety cover as shown in figure 1.
Do not remove safety cover by pulling
up on leads!
3. Remove white core from lower reservoir
by grasping core with one hand and lift-
ing directly up as shown in figure 2.
4. Open doors on the core assembly by
pulling up on the white latches, as shown
in figure 3.
1
2
3
