3. Advanced Commands
Receive (Awnser)
Data [6] \x63
Data [7] \x72
Data [8] \x65
Data [9] \x65
Data [10] \x6e
Data [11] \x00
Data [0] \x32
Data [1] \x62
Data [2] \x76
Data [3] \x32
Data [4] \x20
Data [5] \x72
Data [6] \x61
Data [7] \x73
Data [8] \x74
Data [9] \x65
Data [10] \x72
Data [11] \x00
Checksum \x44
Stop \xff
3.2.7 PiP current layout, Read
Description
Returns the current PiP layout.
Command
Command [0] \x12
Command [1] \x05
Returned Data
strPipname = string
The string is of the C-language type see chapter "1. Serial communications Basics", "Syntax", page 9
Example
Reads the actual PiP layout , result = Full screen.
Transmit
Start \xfe
Projector address \x01
94 R5976884 RLM SERIES 04/04/2006
