3. Advanced Commands
Returned Data
strPipname1
...
strPipnameN
The strPipname and strMask strings are of the C-language type. see chapter "1. Serial communications Ba-
sics", "Syntax", page 9
Example
Reads the actual PiP layout list using the wildcard (*), i.e. returns all the layouts.
Result = Full screen, 2by2 layout.
Transmit
Start \xfe
Projector address \x01
Command[0] \x12
Command[1] \x04
Data[0] \x2a
Data[1] \x00
Checksum \x41
Stop \xff
Receive (acknowledge)
Start \xfe
Projector address \x01
Command[0] \x00
Command[1] \x06
Checksum \x07
Stop \xff
Receive (Awnser)
Start \xfe
Projector address \x01
Command[0] \x12
Command[1] \x04
Data [0] \x46
Data [1] \x75
Data [2] \x6c
Data [3] \x6c
Data [4] \x2d
Data [5] \x73
R5976884 RLM SERIES 04/04/2006 93
