Page 69
2. Basic Commands
Command
Command [0]
\x63
Data
Data[0] = unsigned byte
data value: 1= lamp1 ; 2=lamp2
Returned Data
string = Pascal-language string.
2.31 Image files
2.31.1
File, write
Description
This command writes an image file to the projector, this can be used to write to the projector a previously backed up file (on PC)
which has been read with the “file, read” command.
The string used to represent the filename is of the C-string type.
Command
Command [0]
\xbe
Data
strFilename = string of the C-string type representing the filename: Example of filename : [email protected]
By default the file will be selected in the Custom directory. If the necessary file is a standard file then strFile-
name should be /Standard/[email protected].
FileData = data (ASCII coded) in XML format representing the file.
Example of FileData for the [email protected] file :
The data must be XML “valid” i.e. all the rules (for example for opening/closing tags) must be respected.
R5976884 RLM SERIES 04/04/2006
67
