2. Basic Commands
Receive (acknowledge)
Start \xfe
Projector address \x01
Command[0] \x00
Command[1] \x06
Checksum \x07
Stop \xff
2.9 Source selection
Description
Selects an input source.
Command
Command [0] \x38
Data
Data[0] = bySource, byte describing the source to be linked to the window.
Byte value source
1 BNC’s
2 D15
3 Composite video
4 SVideo
5 DVI
6 Firewire
7 SDI
8 IQ PC
For more info about the input configurations, see the projector’s Owner’s manual.
Data[1] = byMode
for BNC’s and D15: the data byte gives the type of signal present on the BNC’s/D15
Byte value Mode
0 RGBHV
1 RGBCS (analog 4 )
2 RGBCS (digital)
3 RG
s
B
100 ( x\64 ) PrYPb
101 (x\65) RGB video
102
(x\66)
RG
S
B video
4. the signal present on the Cs signal is a composite video signal containing the composite sync
46 R5976884 RLM SERIES 04/04/2006
