3. Advanced Commands
Command
Command [0] \x12
Command [1] \x11
Returned Data
Returned data is 4 times following data :
Data [0] = Window type byte ; 0 = Data A ; 1 = Video A ; 2 = Data B ; 3 = Video B
Data [ 1] = Window visible byte ; 0 = NO ; 1 = YES
Data [2] = file found byte ; 0 = NO ; 1 = YES
Data [3] = input selection byte
for video windows : 0 = decoder layer1; 1 = decoder layer3 ; 4 = SDI ; 0xff = None
for data windows : 0 = data ; 1 = SBC ; oxff = None
Data [4] = source selection word
for video windows
word value Source
0 video
1 VS
2 R
3 G
4 B
5 Lum
6 Chr
7 Video2
20 PrYPb on RGB
21 RGB video on RGB
22 RG
s
B video on RGB
100 S-video
101 S-Video2
102 S-Video3
103 S-Video4
300 SDI
0xff none
for data windows:
word value source
0 RGBHV
1 RGBC
S
(digital)
2 RGBC
S
(analog) 6
3 RG
S
B
100 DssPryPb
6. the signal present on the Cs signal is a composite video signal containing the composite sync
112 R5976884 RLM SERIES 04/04/2006
