background image

9

Main Motor

Leeson A4SI7DR56

Horsepower

1/3 HP

Motor Voltage

115 volt/60Hz / 220 volt/50Hz

Amperage

5.8 Amps / 3.5 Amps

Motor RPM

1725 RPM Fixed / 1425 RPM

Blade Shaft

5/8"

Duty

Continuous

Motor Arbor Bearings

Ball Bearings, permanently sealed

Arbor Diameter

5/8"

Blade Capacity

8", 9" or 10" diameter

Dimensions L x W x H

27" x 17" x 19"

Power Feed Motor

REX

Horsepower

1/15 HP

Motor Voltage

110 volt/60Hz / 230 volt / 50/60Hz

Motor RPM

5 RPM (full load) Fixed

Torque

50 inch-lbs.

Rotation

Clockwise facing the shaft

Motor Arbor Diameter

5/16"

Motor Arbor Bearings

Sleeve-bushing type, permanently sealed

POWER FEED TOGGLE SWITCH CONTROL POSITIONS

1. ON/POWER FEED Position – Provides power from the main motor to the blade arbor and power feed motor.

2. OFF Position – Both power feed and main motors off.

3. MANUAL FEED position - Provides power from the main motor to the blade arbor.

Blade Arbor Bearings: Permanently sealed 5/8" OD shaft ball bearings press fit into aluminum housing (must be

ordered with aluminum housing as an arbor assembly when bearings are worn out.)

Blade Arbor Flanges: Aluminum, 2" OD x 5/8" bore.

Power Feed Threaded Rod: 18" long x 3/8"-24 left hand thread stainless steel rod.

Power Feed Clutch Block: Two piece: silicon bronze half-threaded 3/8"-24 thread friction block.

Rock Vise Capacity: 3-1/4". (Maximum opening between clamping studs)

Cross Feed Index Movement per Revolution of Handle: 1/16".

Power Feed In-Feed Vice Advancement Rate: approximately 3/16 of an inch per minute.

Blade Lubricant Requirements: 0.31 gallon of oil to adequately cover the bottom of a 10” blade and 0.62 gallon

for an 8” blade (Fig. 2).

Shipping Weight

80 lbs. crated (70lbs. uncrated)

Depth of Cut

3" manual feed, 2-5/8" with vise

Oil Capacity

10" Blade, 0.31 gallon; 8" blade 0.62 gallon

BD-10

SPECIFICATION
