25

Item

Part Description

Part#

Quantity

1

Nut, Hex, 5/16 - 18

101196

4

2

Wrench, Tilesaw, 15/16 csd end

134684

1

3

Flange, Outer, 2 - 3/8

135830

2

4

Bearing, Ball, 17 x 40 x 12mm

137711

2

5

Screw, Soc HD Cap, 1/4 - 20 x 1

151049

4

6

Screw, 10 - 32 x 1/2 Pan Head Phillips Machine

151052

11

7

Washer, Lock, Split, 5/16

151747

4

8

Washer, Flat, SAE, 5/16

151754

8

9

Nut, Hex, 1/4 - 20

151893

9

10

Washer, 1/4 Sae Flat

151915

14

11

Screw, Hex HD, 1/4 - 20 x 3/4

152370

4

12

Belt, Micro-V AX-27

152404_BD10

1

13

Screw, Rnd HD, #8 - 32 x 1/2

152517

1

14

Washer, 1/4 Split Lock

152591

5

15

Plug, Rbbr Drain W/o Hole

153439-NL

1

16

Washer, #10 Split Lock

153684

8

17

Blade 10" x 5/8"

153696

1

18

Screw, 5/16 - 18 x 1 - 1/4 Hex Head Machine

153950

4

19

Washer, #10 Sae Flat

154369

13

20

Washer, flat, sae, #8

155454

2

21

Bushing, Blade 1-5.8 x .050

156269

3

22

Nut, Hex 10 - 32

156269

3

23

Screw, 10 - 32 x 1 Hex Head Cap

156270

2

24

Tag, Serial #, Blank

157500-RW

1

25

Assy, Oil Drain, 1/2NPT

157577-06

1

26

Drive Screw, #7 x 5/16 Round Head

157849

2

27

Bolt, Hex Head Tap, 5/16 - 18 x 2

157938

1

28

Nut, Hex Jam 5.8 - 11UNC LH

158577

1

29

Pulley, 2" x 5.8" Bore

161020

1

30

Guard, Splash

161023

1

31

Guard, Blade PF-10

161068

1

32

Pulley, 2" x 1/2" Bore

161070

1

33

Spacer, Nylon 3/8 LG. x 1/2 OD

161076

2

34

Nut, Wing 3/8 - 16

161715

1

35

Screw, Thunb, 1/4 - 20 x 2.0

161904

1

36

Wrench, 3/16 Hex L-Key

165118

1

37

Hex Cap Screw 1/4 - 20 x 5 - 1/2"

166262

1

38

Power Cord

167180

1

39

Tank, Comp

168789

1

BD10

PARTS LIST
