29
Item Part Description Part# Quantity
1 Nut, Hex, 3/8 - 16 101188 2
2 Washer, Flat, SAE, 3/8 150923 3
3 Screw, 10 -32 x 1/2 Pan Head Phillips Machine 151052 2
4 Washer, #10 SAE Flat 154369 1
5 Screw, Pan HD, 1/4 - 20 x 1/4 157523 1
6 Screw, Soc HD Set 1/4 - 20 x 1/4 157528 1
7 Screw, Set Cup, #10 - 32 x 3/16" S.S. 161038 2
8 Collar, Shaft 1/4 x 1/2 161066 2
9 NUT, WING 3/8 - 16 161715 2
10 KNOB, 1/4 - 20 x 2 Round 165163 1
11 Screw, Pan Head Self Sealing 10 -32 x 3/4 167781 2
12 Screw, Flat HD Phillips, #10 - 32 x 1/2, 18 - 8 S.S. 168284 1
13 Carriage Complete 168794 1
14 Vise, Complete 168800 1
15 Vise Drive Mount 168806 1
16 Rod, Swing Vise 168807 1
17 Threaded Drive Rod 168809 1
18 Guide Rod 168810 1
19 Rock Adjustment Rod 168811 2
20 On/Off Rod 168812 1
21 Mount, Drive & Guide Rod 168813 1
22 Bracket, Clutch Mount 168814 1
23 Clutch Plate, Front 168815 1
24 Clutch Plate, Rear 168816 1
25 Coupler 168820 1
26 Bearing, Ball 3/8" x 1 - 1/8" 168822 1
27 Bearing Guide 168823 1
28 Knob, Vise 168869 1
29 Knob Assembly, Vise 168871 2
30 Bushing, Bronze Flanged 5/16 x 9/16 x 1/2 168873 1
31 Wood Clamp 168875 1
32 Nut, Flanged 1/4 - 20 168879 2
33 Spring, Complete 168891 2
34 Screw, Soc HD cap, 1/4 - 20 x 1 - 3/4 169707 2
BD10 PARTS LIST
